The K series single-shaft crusher is a large-capacity large-scale equipment suitable for crushing various materials. It is especially suitable for crushing tough or medium-hard materials (film, bottles, etc.) that are bundled and packaged. The whole machine adopts swing arm push design and PLC automatic control system to achieve higher output. Depending on the type of crushed materials, the output of this series of shredders is approximately 1,500 kg/h to 9,000 kg/h.
The single-shaft shredder is equipped with a built-in propulsion device, which occupies a small area and increases the internal space of the box. It is an ideal shredder for large-volume materials, suitable for injection molding machine waste, chemical blue barrels/barrels, trash cans, pallets, films, blow molding machine waste, carpets, wood, kitchen and domestic waste and other wastes. Special models can also be customized according to customer needs. Siemens PLC can automatically control, stop, reverse and overload automatic reverse. It has the characteristics of low speed, large torque and low noise.
1.It has high-efficiency shredding capacity and provides large shearing force to ensure high crushing output.
2.Reducer with rubber vibration damping to protect transmission parts.
3.The angle of the movable knife can be changed and used multiple times.
4.The fixed knife is adjustable to maintain the gap between the fixed knife and the movable knife.
5.Screen replacement is easy.
6.High-speed swing arm pushing system to maximize output.
7.Rotor quick access door for easy maintenance.
8.Two-speed hydraulic system with air cooling.
9.Independent control electrical box, controlled by Siemens PLC.
10.The whole system complies with CE safety standards.
| K series | ||
| Model | K1500 | K2000 |
| Overall dimensions (L*W*H) (mm) | 2230 x 3660 x2970 | 2230 x3710 x2970 |
| Hopper size (L*H) (mm) | 1360x1910 | 1360 x2410 |
| Discharge height (mm) | 460 | 460 |
| Rotation diameter (mm) | Ф465 | Ф465 |
| Knife roller length (mm) | 1500 | 2000 |
| Speed (RPM) | 80 | 80 |
| Swing arm stroke (mm) | 420 | 420 |
| Number of knives | 88 | 95 |
| Number of fixed knives | 3+3 | 4+4 |
| Motor power (kw) | 110 | 75+75 |
| Hydraulic station power (kw) | 11 | 11 |
| Weight(kg) | Approx 12500 | Approx 15000 |
