The trommel screen is a kind of screening equipment that classifies materials according to their particle size. It mainly consists of a motor, reducer, drum device, frame, sealing cover, inlet and outlet, etc. The overall structure is solid, the screen penetration rate is high, the screen holes are not easy to be blocked, and the screening effect is good. The entire system adopts an effective fully sealed structure and is equipped with interfaces for dust removal and deodorization systems, so it does not raise dust or pollute the environment.
The motor is connected to the drum device through the reducer through a coupling, and drives the drum device to rotate around its axis. When the material enters the drum device, due to the tilt and rotation of the drum device, the material on the screen surface is flipped and rolled, so that the qualified materials (products under the screen) are discharged through the screen mesh on the outer circle of the drum, and the unqualified materials (products on the screen) are discharged ) is discharged through the end of the drum.
1. Adopting the rolling conveying principle, the friction coefficient is small, the wear is low, and the screen holes are not easily clogged.
2. The drum support adopts an integral shaft structure, which ensures smooth and reliable operation and high screening efficiency.
3. Completely sealed structure, equipped with interfaces for dust removal and deodorising systems, no dust or pollution.
4. Adopt reduction gear, which has high transmission efficiency, low power consumption and saves energy consumption.
| Model | Specifications(m) | Diameter(mm) | Speed(rpm) | Power(kW) |
| GTS1230 | Φ1.2×3 | Φ1200 | 12-17 | 4-5.5 |
| GTS1530 | Φ1.5×3 | Φ1500 | 12-17 | 5.5-11 |
| GTS1550 | Φ1.5×5 | Φ1500 | 12-17 | 11-15 |
| GTS1850 | Φ1.8×5 | Φ1800 | 10-15 | 11-18.5 |
| GTS2060 | Φ2.0×6 | Φ2000 | 10-15 | 18.5-22 |
| GTS2580 | Φ2.5×8 | Φ2500 | 10-15 | 22-37 |
