The plastic crusher adopts a sturdy welded steel structure to meet the waste recycling requirements of different industries. The machine cutting uses high-speed rotating blades and uses a small-diameter screen to break the materials into smaller particles at one time. It can also be used as secondary crushing equipment to improve recycling efficiency.
1. The main shaft adopts high-strength welded steel structure and unique V-shaped design, which greatly improves the shredding efficiency. All spindles have passed strict dynamic and static balance tests to ensure the reliability of the machine.
2. The bearing seat is installed on the outside of the machine body, and the main shaft and the machine body are sealed by a sealing ring, which effectively prevents broken objects in the machine body from entering the bearing, thereby extending the service life.
3. Screen mesh of various sizes can be provided according to demand.
4. Hydraulic device facilitates the replacement and maintenance of blades and screens.
1.Compact design saves space.
2.Inclined upper and lower split box for easy blade replacement.
3.High safety factor bearings reduce the chance of bearing damage.
4.Precise spindle processing (front V-shaped spindle is standard configuration).
5.Equipped with replaceable wear plates at both ends of the spindle.
6.Standard models can be equipped with air blowing devices.
7.Independent control electrical box, Siemens PLC.
8.The whole system complies with CE safety standards.
| Model | GC600T | GC800 | GC800T |
| Overall dimensions (Lx WxH) (mm) | 1380x1170x2200 | 1380x1370x2200 | 1580x1440x2300 |
| Hopper opening (LxH) (mm) | 560x615 | 760x615 | 760x615 |
| Rotation diameter (mm) | Φ320 | Ф320 | Ф420 |
| Knife roller length (mm) | 600 | 800 | 800 |
| Speed (RPM) | 580 | 580 | 580 |
| Screen aperture (mm) | Ф12 | Ф12 | Ф12 |
| Number of knives | 3x2 | 3x2 | 3x2 |
| Number of fixed knives | 2x1 | 2x1 | 2x1 |
| Motor power(kw) | 22 | 30 | 37 |
| Weight(kg) | Approx 1500 | Approx 1800 | Approx 3000 |
