The vibrating screen is a sorting equipment that separates materials of different sizes and shapes through the rolling of discs. By adjusting the disc gap, materials with large size differences can be separated. When the equipment is working, the materials are impacted, spread, jumped and rolled on the receiving surface of the rotating polygonal plate. All polygon plates rotate in the same direction as the rollers, causing the garbage on the polygon plates to move horizontally. During the movement, the garbage materials with a particle size smaller than the gap of the disc leak out from the gap on the side of the polygonal disc, thereby realizing the screening function.
This equipment can be equipped with a frequency converter to adjust the rotation speed of the multi-angle disc shaft, and the screening particle size can be moderately adjusted within a certain range. The screen hole is composed of a rotating polygonal disk and an isolation sleeve. The rotating action of the polygonal power disc screen always keeps the screen holes in a dynamic changing process, thereby avoiding screen clogging.
① The processing capacity is large and the total area is very small.
② The screen hole can be adjusted from 10 to 200mm according to the material and screening purpose.
③ Using a hexagonal or octagonal arc-shaped modular design, the appropriate number of modules can be selected according to the user's requirements, making maintenance easy.
④ The high-speed rotating hexagonal or octagonal can cause high-frequency impact on the material, separate the dust or soil adhering to the material from the material, and improve the surface cleanliness of the material.
⑤ The high-frequency hexagonal or octagonal screen drives the material to bounce through, which can minimize the leakage of slender strip materials from the screen holes, and has a better screening effect than the drum screen.
⑥ Patented multi-layer sleeve anti-material jamming design, and a patented anti-winding design for large screen holes, which can prevent hard materials from jamming or flexible long materials from being entangled.
⑦ The processing capacity is 4 times that of the traditional trommel screen of the same size, and the screening efficiency is 1.5 times that of the trommel screen.
⑧ Adopting variable frequency stepless speed control, the energy consumption is very low and the safety performance is high. The processing capacity can be adjusted according to the user's needs.
⑨ Use wear-resistant sprocket chain, chain linkage, and unique tensioning chain design to make the operation more stable.
⑩Applicable to all kinds of solid waste.
| Model | SDS1630 | SDS1650 |
| Power(KW) | 7.5 | 7.5X2 |
| Number of motors (units) | 1 | 2 |
| Working surface size (LXW) (M) | 3X1.6 | 5X1.6 |
| Sieve hole size (MM) | 20-350 | 20-350 |
| Electric control | frequency conversion | frequency conversion |
| Equipment weight(KG) | ~3500 | ~5500 |
| Design processing capacity (T/H) | 15-20 | 18-20 |
